MITSUBISHI (NF100-SN) 100A 3P MCCB

Name: MITSUBISHI (NF100-SN) 100A 3P MCCB
Brand: RAJ ELECTRICALS

Get a Price/Quote

MOQ : 5 Pieces

MITSUBISHI (NF100-SN) 100A 3P MCCB Specification

Phase
Three Phase

Rated Short Circuit Making Current
Approx. 75 kA

Mechanical Life
10,000 operations or more

Rated Short Circuit Breaking Current
36 kA

Breaking Capacity
36 kA (at 415V AC)

Product Type
Moulded Case Circuit Breaker (MCCB)

Installation Options
Panel Mounting

Function
Overcurrent and Short Circuit Protection

Poles Number
3 Poles

Rated Voltage
AC 415V

Rated Current
100A

Rated Frequency
50/60 Hz

Curves
Standard (Inverse time/Instantaneous)

Temperature Protection
Bi-metallic thermal trip

Weight
Approx. 1.6 kg

Color
Grey/Black

Auxiliary Contact Option
Available (optional accessory)

Standards
IEC 60947-2, JIS C8201-2-1

Ambient Operating Temperature
-5C to +40C

Model
NF100-SN

Degree of Protection
IP20 (device only)

Mounting Orientation
Any (vertical/horizontal)

Rated Impulse Withstand Voltage (Uimp)
8 kV

Trip Type
Thermal Magnetic

Rated Insulation Voltage (Ui)
690V AC

Terminal Type
Screw Terminal

MITSUBISHI (NF100-SN) 100A 3P MCCB Trade Information

Minimum Order Quantity
5 Pieces

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Letter of Credit (L/C)

Sample Available
Yes

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

About MITSUBISHI (NF100-SN) 100A 3P MCCB

MITSUBISHI (NF100-SN) 100A 3P MCCB Available In Stock At Raj Electricals, Bhavnagar, Gujarat, India.

We are engaged in the supply, dealing, distribution, export and import of the widest range of electrical and electronic items that would suit every type of project, economy and medium.

Product Specification :-

Type :- MCCB (Moulded Case Circuit Breaker)

Make :- MITSUBISHI

Ampere :- 100A

Pole :- 3P

Model :- NF100-SN

Condition :- Refurbished

Breaking Capacity :- 25 kA

Voltage :- 220V AC

Frequency :- 50-60 Hz

For More Details

WhatsApp or call on :- +919426838080, +919904838080.

YouTube : https://www.youtube.com/@rajelectricals5253

Google : https://g.co/kgs/WCmt5a

Instagram : https://www.instagram.com/rajelectric52/

Facebook : https://www.facebook.com/RajElectricals52/

Website : https://www.rajelectrics.com/

Reliable Protection for Power Systems

The MITSUBISHI NF100-SN MCCB is engineered to safeguard electrical circuits against overload and short circuits. Its standard trip curves and dependable bi-metallic thermal trip mechanism ensure swift response during fault conditions. With a robust breaking capacity of 36 kA, this breaker is suitable for heavy-duty industrial and commercial distribution networks.

Versatile Installation Options

Designed to accommodate diverse installation environments, the NF100-SN supports both vertical and horizontal mounting within a panel. Its screw terminal construction simplifies wiring and enhances connection reliability. The compact, durable design-featuring an IP20-rated enclosure-makes it adaptable for various panel mounting requirements.

Optional Auxiliary Features for Enhanced Control

The NF100-SN offers an optional auxiliary contact accessory, perfect for advanced circuit monitoring and remote signaling. System integrators and panel builders can implement additional operational feedback or alarms, gaining improved visibility and control of their power distribution systems.

FAQ's of MITSUBISHI (NF100-SN) 100A 3P MCCB:

Q: How does the MITSUBISHI NF100-SN MCCB provide circuit protection?

A: The NF100-SN uses both thermal and magnetic trip mechanisms to protect electrical circuits from overloads (using a bi-metallic strip) and short circuits (via an electromagnetic trip) for reliable system safety.

Q: What are the installation options and orientations for the NF100-SN breaker?

A: This MCCB is designed for panel mounting and can be installed in any orientation-vertical or horizontal-making it flexible for diverse panel layouts.

Q: When should I use the optional auxiliary contact with this MCCB?

A: The optional auxiliary contact is useful when remote monitoring, operational signaling, or integration with automated control systems is required, allowing for enhanced system management.

Q: Where can the NF100-SN be used within an electrical system?

A: It is suitable for use in industrial and commercial distribution panels, particularly in three-phase AC circuits up to 415V, delivering robust protection for feeders and sub-panels.

Q: What benefits does the high breaking capacity of 36 kA provide?

A: A 36 kA breaking capacity allows the MCCB to safely interrupt high prospective fault currents, ensuring both equipment protection and personnel safety in demanding environments.

Q: How does the device ensure consistent performance over time?

A: With a mechanical life of over 10,000 operations and construction compliant with IEC and JIS standards, the NF100-SN delivers reliable long-term operation even under frequent switching.
