HAVELLS 32A 4P RCCB

Get a Price/Quote

HAVELLS 32A 4P RCCB Specification

Connector Type
Screw Terminals

Shape
Rectangular

Operating Temperature
-5C to +40C

Mounting Type
DIN Rail

Surface Finish
Matte

IP Rating
IP20

Overheating Protection
YES

Feature
Earth Leakage Protection, Double Breaking Mechanism

Power Factor
--

Insulation Material
Flame Retardant Plastic

Efficiency
High

Humidity %
Up to 95% RH

Product Type
Residual Current Circuit Breaker (RCCB)

Application
Electrical safety, leakage protection in industrial and residential installations

Protection Level
30 mA Sensitivity

Frequency (MHz)
50/60 Hz

Rated Voltage
415V AC

Energy Consumption
Low

Output Type
Four Outputs

Color
White & Green

Dimension (L*W*H)
91 mm x 80 mm x 68 mm

Weight
350 g

Size
Standard Modular Size

Input Voltage
415V AC

Phase
Three Phase

Material
High-grade plastic and copper components

Connection Type
DIN Rail Mounting

No Of Poles
4 Pole (4P)

HAVELLS 32A 4P RCCB Trade Information

Minimum Order Quantity
5 Number

Payment Terms
Cash Advance (CA), Cash in Advance (CID)

Sample Available
Yes

Main Export Market(s)
Asia

Main Domestic Market
All India

About HAVELLS 32A 4P RCCB

Havells 32A 4P RCCB Available In Stock At Raj Electricals, Bhavnagar, Gujarat, India.

We are engaged in the supply, dealing, distribution, export and import of the widest range of electrical and electronic items that would suit every type of project, economy and medium.

Product Specification :-

Type :- Moulded Case Circuit Breaker (Mccb)

Make :- Havells

Ampere :- 32A

Number Of Pole :- 4P

Country Of Origin :- India

Breaking Capacity :- 10 kA

We Supply Our Product In All Over India And Also In Foreign Countries.

For More Details Contact :9426838080.

Website:www.rajelectrics.com

Email: raj_electricals@hotmail.com.

Superior Earth Leakage Protection

The HAVELLS 32A 4P RCCB provides top-tier protection against electrical leakage, with a high sensitivity of 30 mA and breaking capacity of 10 kA. Its rapid response under 100 ms mitigates risks, preventing electrical shocks and potential fire hazards in residences, offices, and industrial environments.

Durable, Safe Design for Versatile Use

Constructed from flame-retardant plastic and copper, this RCCB boasts an insulated, shockproof body and matte finish. Its robust mechanism is built for over 10,000 mechanical and 4,000 electrical operations, performing reliably across a wide range of temperatures, humidity, and mounting positions.

Effortless Installation and Maintenance

The unit features a standard modular size and attaches easily to DIN rail systems both vertically and horizontally. Clear screw terminals allow secure connections, while the provided test button facilitates routine safety checks, ensuring ongoing performance with minimal energy consumption.

FAQ's of HAVELLS 32A 4P RCCB:

Q: How does the HAVELLS 32A 4P RCCB enhance electrical safety?

A: This RCCB detects earth leakage currents above 30 mA and swiftly trips the circuit in less than 100 ms. By interrupting faulty circuits, it prevents electric shocks and reduces the risk of fire, making it essential for residential, office, and industrial safety.

Q: What is the correct process for installing the HAVELLS 32A 4P RCCB?

A: For installation, mount the RCCB on a DIN rail in either vertical or horizontal position. Secure your wiring using the marked screw terminals for the four poles, ensuring connections are tight and in accordance with wiring diagrams. Professional installation is recommended to ensure adherence to safety standards.

Q: When should I use the Test Button on the RCCB?

A: It is advisable to press the test button at least once every month to verify the operational integrity of the RCCB. This simulates a fault by initiating a safe earth leakage, ensuring the device trips promptly and continues to protect your system.

Q: Where can the HAVELLS RCCB be installed for optimal protection?

A: This device is suitable for installation in homes, offices, and industrial facilities. It integrates with three-phase electrical systems where protection from earth leakage is needed, especially in distribution boards or consumer units.

Q: What are the primary benefits of the toggle switch mechanism?

A: The toggle switch mechanism offers a straightforward and reliable way to manually disconnect or reset the RCCB. This makes it easy and quick to cut power when needed, or restore it safely after maintenance or a tripping event.

Q: How do the product's materials and construction improve performance?

A: The high-grade flame retardant plastic and copper components bolster durability, ensure effective insulation, and withstand high operating temperatures. The shockproof, insulated design provides extra safety in challenging environments.

Q: What makes this RCCB energy efficient in everyday use?

A: Designed with minimal energy consumption, the RCCB operates efficiently without unnecessary power draw, making it cost-effective for continuous operation in both commercial and residential applications.
