TELEMECANIQUE TC1D2510 CONTACTOR

Get a Price/Quote

TELEMECANIQUE TC1D2510 CONTACTOR Specification

IP Rating
IP20

Connector Type
Screw Terminal

Surface Finish
Matte

Power Factor
>0.95

Mounting Type
DIN Rail Mount

Operating Temperature
-5°C to +60°C

Overheating Protection
YES

Shape
Rectangular

Feature
High Durability, Compact Design

Insulation Material
Thermoplastic

Efficiency
High

Humidity %
≤ 95%

Product Type
Contactor

Application
Motor Control, Power Switching

Protection Level
IP20

Frequency (MHz)
50/60 Hz

Rated Voltage
220-240V AC

Energy Consumption
Low

Output Type
Normally Open

Color
Black & Blue

Dimension (L*W*H)
44 mm x 85 mm x 98 mm

Weight
0.6 kg

Phase
Three Phase

Input Voltage
220-240V AC

Size
Standard

No Of Poles
3

Connection Type
Screw Terminal

Material
Plastic and Metal

Short Circuit Withstand Capacity
1 kA

Operating Position
Any

Ambient Storage Temperature
-40°C to +70°C

Model Number
TC1D2510

Contact Configuration
3NO + 1NC

Max Cable Size
2.5 mm²

Coil Voltage
220V AC

Auxiliary Contacts
1NO

Electrical Life
1 Million Operations

Control Circuit Power Consumption
Approx 8 VA

Rated Current
25A

Mechanical Life
10 Million Operations

TELEMECANIQUE TC1D2510 CONTACTOR Trade Information

Sample Available
Yes

Main Export Market(s)
Asia

Main Domestic Market
All India

About TELEMECANIQUE TC1D2510 CONTACTOR

A contactor is an electrical device which is used for switching an electrical circuit on or off. ... These contacts are in most cases normally open and provide operating power to the load when the contactor coil is energized. Contactors are most commonly used for controlling electric motors.

Advanced Motor Control and Efficiency

The TC1D2510 contactor is purpose-built for advanced motor control and frequent switching tasks. Benefiting from high efficiency, low energy usage, and a power factor greater than 0.95, it ensures stable operations. Its quick DIN rail mounting and screw terminal connections facilitate rapid installation in diverse environments.

Exceptional Durability and Reliability

Engineered with premium plastic and metal materials, the contactor boasts a mechanical life of up to 10 million operations and electrical endurance up to 1 million cycles. Its IP20 enclosure offers adequate protection against touch, while integrated overheating protection and high humidity resistance (up to 95%) enhance reliability in challenging conditions.

Optimized Design for Industrial Applications

Compact with dimensions of 44 mm x 85 mm x 98 mm and a matte finish, the TC1D2510 fits seamlessly into panel systems. It's designed for three-phase power, suitable for motor control, power switching, and overload protection, supporting operational temperatures between -5C to +60C and storage down to -40C.

FAQ's of TELEMECANIQUE TC1D2510 CONTACTOR:

Q: How is the TELEMECANIQUE TC1D2510 contactor typically used in industrial settings?

A: The TC1D2510 contactor is mainly used for motor control and power switching in three-phase industrial applications. Its robust build and reliable operation make it ideal for controlling and protecting equipment in manufacturing plants, distribution boards, and automation systems.

Q: What are the installation requirements and mounting options for the TC1D2510 contactor?

A: The TC1D2510 is designed for easy DIN rail mounting and utilizes screw terminal connections, allowing quick and secure installation. Its compact size and standard dimensions enable integration into most industrial control panels without requiring significant space adjustments.

Q: When should I choose this contactor over other models?

A: Select the TC1D2510 when you require high durability (mechanical life of up to 10 million operations), compact design, low power consumption, and reliable performance under varying environmental conditions. The model's adaptability and robust IP20 rating suit demanding industrial applications.

Q: Where can the TC1D2510 operate in terms of temperature and humidity?

A: The contactor operates reliably within temperatures from -5C to +60C and can be stored between -40C and +70C. Its design ensures optimal performance in environments with humidity levels up to 95%, making it suitable for a variety of challenging climate conditions.

Q: What processes does the TC1D2510 aid in?

A: The TC1D2510 contactor facilitates key processes such as starting, stopping, and controlling electric motors, as well as switching power circuits. It is integral to automated control systems, offering effective overload protection and circuit isolation.

Q: What is the benefit of the contactor's auxiliary contact (1NO)?

A: The auxiliary normally open (1NO) contact enhances system flexibility by enabling signaling functions and status indication. This feature supports system monitoring, interlocking, and advanced control schemes in industrial automation.
