TELEMECANIQUE LC1F265 CONTACTOR

Get a Price/Quote

TELEMECANIQUE LC1F265 CONTACTOR Specification

Operating Temperature
-5°C to +60°C

Connector Type
Screw/Bolt Terminal

Mounting Type
DIN Rail / Panel

Shape
Rectangular

Power Factor
0.85

Efficiency
>95%

Feature
High Mechanical Durability, Easy Coil Replacement

Overheating Protection
YES

Surface Finish
Textured

IP Rating
IP20

Insulation Material
Thermoplastic

Humidity %
Up to 95% RH

Product Type
Power Contactor

Application
Industrial Motor Control

Protection Level
AC-3

Frequency (MHz)
50/60 Hz

Rated Voltage
690V AC

Energy Consumption
Low

Output Type
NO/NC Contacts

Color
Black and Grey

Dimension (L*W*H)
190 x 230 x 205 mm

Weight
18 kg

Input Voltage
220-240V AC Coil

Phase
Three Phase

Size
265A Frame Size

Connection Type
Screw Terminal

Material
High-grade Thermoplastic and Metal

No Of Poles
3

Contact Material
Silver Alloy

Vibration Resistance
5g

Auxiliary Contacts
2 NO + 2 NC

Mechanical Endurance
1,000,000 cycles

Rated Current
265A

Electrical Endurance
100,000 cycles

Coil Consumption
98 VA (at pickup)

Shock Resistance
15g

TELEMECANIQUE LC1F265 CONTACTOR Trade Information

Sample Available
Yes

Main Export Market(s)
Asia

Main Domestic Market
All India

About TELEMECANIQUE LC1F265 CONTACTOR

A contactor is an electrical device which is used for switching an electrical circuit on or off. ... These contacts are in most cases normally open and provide operating power to the load when the contactor coil is energized. Contactors are most commonly used for controlling electric motors.

Superior Performance for Industrial Motors

Designed specifically for demanding industrial applications, the LC1F265 handles up to 265A and runs on a three-phase supply. Its silver alloy contact material, high shock and vibration resistance, and IP20 protection ensure both safety and longevity. The contactor's low coil consumption and high mechanical durability make it a reliable choice for continuous operations.

Effortless Installation and Maintenance

The LC1F265 features a user-friendly design with screw/bolt terminals for secure connections and offers both DIN rail and panel mounting options. Its easy coil replacement mechanism reduces downtime during maintenance. The compact, rectangular shape with a textured surface finish adds practicality and resilience in industrial settings.

FAQ's of TELEMECANIQUE LC1F265 CONTACTOR:

Q: How is the TELEMECANIQUE LC1F265 contactor installed in industrial settings?

A: Installation is straightforward, as the contactor supports both DIN rail and panel mounting types. Connection is made via screw or bolt terminals, ensuring a secure and stable setup for industrial motor control applications.

Q: What benefits does using silver alloy contacts provide in the LC1F265?

A: Silver alloy contacts offer excellent electrical conductivity and reduced wear, which translates to longer operational life and reliable switching under high-load industrial conditions.

Q: When should the coil of the LC1F265 contactor be replaced?

A: Coil replacement is recommended if you notice erratic operation or failure to pull in, though the contactor is designed for easy coil replacement to minimize downtime. Always ensure power is disconnected before servicing.

Q: Where can the LC1F265 contactor be used?

A: This contactor is suited for a wide range of industrial motor control settings, such as manufacturing plants, automated production lines, and heavy-duty equipment, particularly where high reliability and endurance are required.

Q: What is the process for maintaining the LC1F265 contactor?

A: Routine maintenance involves inspecting terminals, checking for wear on contacts, and ensuring the coil functions correctly. The design allows access for easy servicing and component replacement, improving uptime in industrial environments.

Q: How does the LC1F265 contactor ensure operational safety and efficiency?

A: With an AC-3 protection level, high mechanical endurance, IP20 enclosure, and overheating protection, the contactor delivers operational reliability while maintaining energy efficiency (>95%) and safety for industrial users.
