Mitsubishi S-N25 Contactor

Get a Price/Quote

Mitsubishi S-N25 Contactor Specification

Operating Temperature
-5°C to +40°C

Overheating Protection
Built-in Thermal Protection

Efficiency
High

Power Factor
0.9

Feature
High Durability, Reliable Operation

Humidity %
Max 85% RH

Mounting Type
DIN Rail/Panel Mount

Surface Finish
Matte

Connector Type
Screw Connector

Shape
Rectangular

Insulation Material
Polycarbonate

IP Rating
IP20

Product Type
AC Contactor

Application
Power Control, Motor Starters

Protection Level
IP20

Frequency (MHz)
50/60 Hz

Rated Voltage
AC 220V

Energy Consumption
Low Power Consumption

Output Type
Normally Open (NO)

Color
Black and White

Dimension (L*W*H)
80mm x 45mm x 98mm

Weight
0.75 kg

Input Voltage
AC 220V

Size
Standard

Phase
Three Phase

No Of Poles
3

Connection Type
Screw Terminal

Material
Flame Retardant Plastic & Metal

Coil Voltage Options
AC 110V/220V/380V

Altitude
Up to 2000m

Contact Material
Silver Alloy

Storage Temperature
-25°C to +55°C

Rated Current
25A

Ambient Air Temperature
Up to 50°C

Electrical Life
1 Million Operations

Vibration Resistance
Yes

Short Circuit Protection
Yes

Standards
IEC/EN 60947-4-1

Auxiliary Contacts
1NO+1NC

Mechanical Life
10 Million Operations

Mitsubishi S-N25 Contactor Trade Information

Payment Terms
Cash in Advance (CID)

Sample Available
Yes

Main Domestic Market
All India

About Mitsubishi S-N25 Contactor

A contactor is an electrical device which is used for switching an electrical circuit on or off. ... These contacts are in most cases normally open and provide operating power to the load when the contactor coil is energized. Contactors are most commonly used for controlling electric motors.

Designed for Efficiency and Durability

Built with a flame-retardant plastic and metal housing, the Mitsubishi S-N25 ensures both safety and longevity. Its high mechanical and electrical life cycles make it a preferred choice for continuous operation in industrial settings. Advanced protection mechanisms preserve critical components and extend service intervals.

Flexible Installation Options

The S-N25 offers compatibility with both DIN rail and panel mounting, allowing easy integration into varied electrical systems. Its screw terminal and connector types, together with standard dimensions (80mm x 45mm x 98mm), provide secure and straightforward wiring for three-phase power applications.

FAQ's of Mitsubishi S-N25 Contactor:

Q: How do I install the Mitsubishi S-N25 Contactor in my electrical system?

A: The S-N25 can be mounted on a DIN rail or panel, using standard screw terminals for secure electrical connections. Ensure the ambient temperature is within -5C to +40C and follow the wiring diagram provided in the manual.

Q: What applications is the S-N25 Contactor best suited for?

A: This contactor is ideal for power control and three-phase motor starters in industrial and commercial installations, thanks to its high reliability, built-in thermal protection, and compliance with IEC/EN 60947-4-1.

Q: When should the contactor be serviced or replaced?

A: Routine inspection is recommended based on operational cycles. Given its 10 million mechanical and 1 million electrical life, service or replacement should be considered as it approaches these operational thresholds or shows signs of wear.

Q: Where can I use the S-N25 Contactor in terms of environmental conditions?

A: It operates reliably in environments up to 50C ambient temperature, up to 85% relative humidity, and altitudes up to 2000m. The IP20 rating makes it suitable for protected indoor locations.

Q: What are the benefits of using a silver alloy contact material in the S-N25?

A: Silver alloy contacts provide high conductivity and resistance to arcing, resulting in reliable electrical performance and a longer service life, which reduces maintenance needs.

Q: How does the built-in thermal protection enhance safety?

A: The integrated thermal protection automatically disconnects the circuit in case of overheating, preventing potential damage to the connected equipment and enhancing operational safety.
