MITSUBISHI S-N150 CONTACTOR

Get a Price/Quote

MITSUBISHI S-N150 CONTACTOR Specification

Operating Temperature
-10°C to +40°C

Feature
Long service life, High electrical endurance, Easy coil replacement

Power Factor
0.85 min.

Efficiency
High

Insulation Material
Thermoplastic

Shape
Rectangular

Connector Type
Screw Type

Surface Finish
Molded

Humidity %
5 - 95% RH

Mounting Type
Panel Mount

IP Rating
IP20

Overheating Protection
No built-in; needs external relay

Product Type
Contactor

Application
Industrial Motor Control, Power Switching

Protection Level
IP20

Frequency (MHz)
50/60 Hz

Rated Voltage
AC 220V / 240V / 415V

Energy Consumption
160-190 VA (at pick-up)

Output Type
AC Output

Color
White/Black

Dimension (L*W*H)
210 mm × 142 mm × 202 mm

Weight
7.5 kg

Phase
Three Phase

Size
150A class

Input Voltage
AC 220V / 240V / 415V

No Of Poles
3

Material
Plastic, Metal

Connection Type
Screw Terminal

Electrical Life
500,000 Ops

Coil Voltage Options
110V, 220V, 240V, 380V, 415V AC

Mechanical Life
2 Million Ops

Rated Insulation Voltage (Ui)
690V AC

Main Contact Current
150A

Auxiliary Contacts
2 NO + 2 NC

Series
S-N Series

Installation
Indoor

Dielectric Strength
2500V AC for 1 min

Standards Compliance
IEC, JIS, EN60947-4-1

MITSUBISHI S-N150 CONTACTOR Trade Information

Minimum Order Quantity
3 Number

Payment Terms
Cash Advance (CA), Cash in Advance (CID)

Sample Available
Yes

Main Domestic Market
All India

About MITSUBISHI S-N150 CONTACTOR

Mitsubishi S-N150 Contactor Available In Stock At Raj Electricals, Bhavnagar, Gujarat, India.

We are engaged in the supply, dealing, distribution, export and import of the widest range of electrical and electronic items that would suit every type of project, economy and medium.

Product Specification :-

Type :- Magnetic Contactor

Make :- Mitsubishi

Model Number :- S-N150

AC-1-Ith :- 200A

Number Of Poles :- 3

No. Of Auxiliary Contacts NO :- 2

No. Of Auxiliary Contacts NC :- 2

We Supply Industrial Product In All Over India And Also In Foreign Countries.

For More Details Contact : 9426838080.

Website:www.rajelectrics.com

Email: raj_electricals@hotmail.com.

Advanced Industrial Control Solution

The S-N150 contactor stands out for its suitability in heavy-duty industrial and motor control environments. With an impressive rated current of 150A and a variety of coil voltages ranging from 110V to 415V, it seamlessly integrates into systems requiring reliable power switching. Its robust plastic and metal construction, combined with a molded surface finish and IP20 protection, offers durability and safety.

Reliable and Efficient Performance

Built for efficiency, the S-N150 features a high electrical endurance and long mechanical life. The easy coil replacement minimizes downtime during maintenance, while the screw terminal connections allow straightforward wiring. With high dielectric strength and efficient power factor, it suits applications where reliability is essential.

FAQ's of MITSUBISHI S-N150 CONTACTOR:

Q: How do I install the MITSUBISHI S-N150 contactor?

A: The S-N150 is designed for panel mount installation using screw terminals for secure connections. Ensure the device is installed indoors in environments with 5-95% humidity and temperatures between -10C and +40C.

Q: What are the main benefits of using the S-N150 contactor in industrial applications?

A: The S-N150 offers high current capacity (150A), long service life, high electrical endurance, and ease of coil replacement. It is compliant with leading international standards (IEC, JIS, EN60947-4-1), ensuring reliable and safe operation in demanding industrial settings.

Q: When should the auxiliary contacts be used?

A: Auxiliary contacts (2 NO + 2 NC) on the S-N150 are typically used for signaling, interlocking, or control circuit functions, providing additional flexibility in system design and enhancing control options.

Q: Where is the S-N150 contactor most commonly used?

A: The S-N150 is primarily used in industrial environments for motor control, power switching, and large machinery operations. It's suitable for applications such as manufacturing plants, processing facilities, and automated systems.

Q: What standards does the S-N150 comply with, and why is this important?

A: The S-N150 meets IEC, JIS, and EN60947-4-1 standards, which guarantees safety, compatibility, and performance consistency, making it suitable for international deployments and certified systems.

Q: Does the S-N150 contactor offer built-in overheating protection?

A: No, the S-N150 does not have built-in overheating protection. For comprehensive system safety, it is recommended to use an external relay for thermal and overload protection.
