200A FUSE BASE

Get a Price/Quote

200A FUSE BASE Specification

Insulation Material
Porcelain

Mounting Type
DIN Rail Mount / Surface Mount

Surface Finish
Glazed

Overheating Protection
Yes (Heat Resistant Porcelain)

Operating Temperature
-10C to 60C

Shape
Rectangular

Connector Type
Bolt/Screw Terminal

IP Rating
IP20

Humidity %
Up to 95% RH non-condensing

Feature
Shockproof, Flame Retardant, Durable Construction

Efficiency
100% (passive)

Product Type
Fuse Base

Application
Distribution Panels, Industrial Electrical Installations

Protection Level
High

Frequency (MHz)
50 Hz

Rated Voltage
415V AC

Energy Consumption
N/A (passive component)

Output Type
Terminal Type

Color
Ivory White and Metallic

Dimension (L*W*H)
145 mm x 55 mm x 42 mm (approx.)

Weight
Approx. 350 grams

Size
Standard size for 200A fuse

Input Voltage
415V AC Max

Phase
Single Phase

Connection Type
Screw Type Clamp

Material
High-grade porcelain base and copper alloy contacts

No Of Poles
1 Pole

200A FUSE BASE Trade Information

Minimum Order Quantity
10 Number

Payment Terms
Cash in Advance (CID), Cash Advance (CA)

Sample Available
Yes

Main Export Market(s)
Asia

Main Domestic Market
All India

About 200A FUSE BASE

Raj Electricals Offering Siemens 200A Fuse-Base At Bhavnagar, Gujarat, India.

We are engaged in the supply, dealing, distribution, export and import of the widest range of electrical and electronic items that would suit every type of project, economy and medium.

Product Specification :-

Type :- Fuse-Base

Make :- Siemens

Ampere :- 200A

Voltage :- 415V

We Supply Industrial Product In All Over India And Also In Foreign Countries.

For More Details Contact : 9426838080.

Website:www.rajelectrics.com

Email: raj_electricals@hotmail.com.

Superior Electrical Protection for Industrial Needs

Designed for demanding applications, the 200A Fuse Base combines high dielectric strength of 2.5 kV for one minute, ensuring excellent insulation and safety. Its high-grade porcelain construction is engineered to withstand challenging electrical environments, providing lasting protection for your distribution panels and switchboards.

Flexible Installation and Reliable Operation

This fuse base features a single pole, rectangular design, and is compatible with both DIN rail and surface mounting, offering installation flexibility. With robust brass terminals, fixing screws included, and a standardized connection profile, it integrates straightforwardly into new projects or existing installations, supporting efficient operation at 415V AC.

FAQ's of 200A FUSE BASE:

Q: How do I install the 200A Fuse Base in my panel board or distribution board?

A: Installation is simple and can be performed on either a DIN rail or via surface mounting, thanks to its standardized screw clamp connectors. The product is supplied with all necessary fixing screws for secure attachment, ensuring a stable and safe electrical connection for industrial use.

Q: What are the safety standards and protection features of this fuse base?

A: The 200A Fuse Base complies with IS 13703 and IEC 60269 standards, delivering reliable safety and performance. Its porcelain base is shockproof and flame retardant, while the IP20 enclosure protects against accidental contact, ensuring a high protection level for operators and equipment.

Q: When should I use this fuse base in my electrical installations?

A: This fuse base is ideal for use in distribution panels, control panels, switchboards, and various industrial electrical installations where a 200A protection is required. It is particularly suitable for applications that demand high short circuit withstand capacity and reliable mechanical performance.

Q: Where can the 200A Fuse Base be operated and stored?

A: It operates efficiently in ambient temperatures ranging from -10C to 60C, with a storage temperature range between -20C and 70C. The base also tolerates humidity up to 95% RH (non-condensing), making it resilient for diverse climates and industrial settings.

Q: What benefits does the spring-loaded copper contact design provide?

A: Spring-loaded copper contacts ensure consistent electrical conductivity and reduce contact resistance, improving the efficiency and longevity of the fuse base. This design enhances safety by maintaining reliable connections throughout repeated mechanical operations.

Q: How does the heat-resistant porcelain ensure overheating protection?

A: The use of high-grade glazed porcelain material provides excellent insulation and resists heat buildup, offering inherent overheating protection critical for maintaining safe operation even under high load or fault conditions.
