FUJI SC-8N (180) CONTACTOR

Name: FUJI SC-8N (180) CONTACTOR
Brand: RAJ ELECTRICALS

Get a Price/Quote

MOQ : 5 Pieces

FUJI SC-8N (180) CONTACTOR Specification

Mounting Type
DIN Rail / Screw Mount

IP Rating
IP20

Surface Finish
Molded

Power Factor
0.8 (Min)

Connector Type
Screw Terminal

Overheating Protection
Available with appropriate relay

Efficiency
High

Shape
Rectangular

Operating Temperature
-5C to +40C

Insulation Material
Thermosetting Resin

Humidity %
Max. 85% RH

Feature
High Durability, Compact Design

Product Type
Contactor

Application
Motor Control, Industrial Automation

Protection Level
IP20

Frequency (MHz)
50/60 Hz

Rated Voltage
220V AC

Energy Consumption
5.6 VA (Coil)

Output Type
NO + NC Contacts

Color
Black & White

Dimension (L*W*H)
72 mm x 76 mm x 107 mm

Weight
275 g

Size
SC-8N (180)

Phase
Three Phase

Input Voltage
220V AC

Connection Type
Screw Terminal

No Of Poles
3

Material
Thermoplastic

Standards Approvals
UL, CE, CSA

Maximum Switching Current
18 A

Auxiliary Contacts
1NO + 1NC

Storage Temperature
-25C to +65C

Coil Voltage Options
220-240V AC / 24V DC

RoHS Compliant
Yes

Short Circuit Withstand Capacity
6 kA (at 220V)

Conformance Standard
IEC 60947-4-1

Mechanical Life
10 Million Operations

Electrical Life
1 Million Operations

Contact Material
Silver Alloy

FUJI SC-8N (180) CONTACTOR Trade Information

Minimum Order Quantity
5 Pieces

Payment Terms
Cash in Advance (CID), Cheque, Letter of Credit (L/C)

Sample Available
Yes

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

About FUJI SC-8N (180) CONTACTOR

FUJI SC-8N (180) CONTACTOR Available In Stock At Raj Electricals, Bhavnagar, Gujarat, India.

We are engaged in the supply, dealing, distribution, export and import of the widest range of electrical and electronic items that would suit every type of project, economy and medium.

Product Specification :-

Type :- Electric Contactor

Make :- Fuji

AC1 :- 260A

Model :- SC-8N (180)

Condition :- Refurbished

Voltage :- 220V AC

Frequency :- 50-60 Hz

For More Details

Whats App or call on :- +919426838080, +919904838080.

YouTube : https://www.youtube.com/@rajelectricals5253

Google : https://g.co/kgs/WCmt5a

Instagram : https://www.instagram.com/rajelectric52/

Facebook : https://www.facebook.com/RajElectricals52/

Website : https://www.rajelectrics.com/

Key Features and Reliability

The FUJI SC-8N (180) Contactor stands out for its high durability, compact design, and efficient operation in demanding industrial environments. With its mechanical life reaching 10 million operations and electrical longevity of 1 million cycles, it promises sustained performance and reduced downtime. The inclusion of a molded thermoplastic case and silver alloy contact material ensures both safety and reliability.

Versatile Applications and Compliance

Engineered for motor control and industrial automation, the SC-8N (180) is ideal for industries seeking RoHS-compliant, high-efficiency contactors. Meeting UL, CE, and CSA approvals, it guarantees global standards conformity. The contactor is tailored for three-phase systems and efficiently supports 220V AC input, making it suitable for a wide array of industrial installations.

FAQ's of FUJI SC-8N (180) CONTACTOR:

Q: How do I install the FUJI SC-8N (180) Contactors in my industrial setup?

A: The SC-8N (180) contactor supports both DIN rail and screw mounting, providing flexibility for installation in control panels or electrical enclosures. Simply follow the wiring diagram provided in the manual and use the screw terminals for secure electrical connections.

Q: What benefits does the silver alloy contact material offer?

A: Silver alloy contacts ensure superior conductivity and resistance to electrical wear, resulting in minimized contact resistance and prolonged equipment life, especially in high-frequency switching environments.

Q: When should I consider using the 24V DC coil voltage option instead of 220-240V AC?

A: You should use the 24V DC coil voltage option when your control system operates on low voltage DC circuits or where electrical isolation and safety are priorities, such as in sensitive automation panels.

Q: Where can the SC-8N (180) contactor be used effectively?

A: This contactor is ideal for motor control and industrial automation applications in factories, process plants, and establishments requiring reliable switching and high durability within a -5C to +40C operating temperature range.

Q: What is the process for ensuring proper protection against overheating?

A: Pair the contactor with an appropriate thermal relay, which detects excess current and prevents overheating, thus safeguarding the motor and contactor from potential damage.

Q: How does the IP20 protection rating benefit the device?

A: An IP20 rating protects against solid objects greater than 12mm, such as fingers or tools, minimizing accidental contact with live parts and ensuring operator safety during handling and operation.

Q: What makes the FUJI SC-8N (180) suitable for demanding industrial environments?

A: With short circuit withstand capacity up to 6 kA, mechanical and electrical longevity, compliance with international standards, and high energy efficiency, the SC-8N (180) thrives in environments where reliability, safety, and performance are paramount.
