FUJI SC-8 STAR DELTA STARTER

Get a Price/Quote

FUJI SC-8 STAR DELTA STARTER Specification

Power Factor
0.8

Mounting Type
Panel Mount

Operating Temperature
-5C to +40C

IP Rating
IP20

Shape
Rectangular

Insulation Material
Thermoplastic

Humidity %
Up to 95% RH

Connector Type
Screw Type

Surface Finish
Matt

Efficiency
High

Feature
High Durability, Compact Design

Overheating Protection
YES

Product Type
Star Delta Starter

Application
Motor Protection/Control

Protection Level
IP20

Frequency (MHz)
50/60 Hz

Rated Voltage
415V AC

Energy Consumption
Low

Output Type
AC

Color
Grey

Dimension (L*W*H)
155 mm x 130 mm x 120 mm

Weight
Approx. 1.85 kg

Input Voltage
415V

Size
SC-8

Phase
Three Phase

Material
High Grade Plastic & Metal

Connection Type
Screw Terminal

No Of Poles
3 Pole

Auxiliary Contacts
1NO+1NC

Coil Voltage
220V / 230V / 240V / 380V / 415V AC

Control Voltage
220-240V AC

Rated Current
18A

Short Circuit Protection
Yes (with recommended breaker)

Standards
IEC 60947-4-1

FUJI SC-8 STAR DELTA STARTER Trade Information

Payment Terms
Cash in Advance (CID)

Sample Available
Yes

Main Export Market(s)
Asia

Main Domestic Market
All India

About FUJI SC-8 STAR DELTA STARTER

Star/Delta starters are probably the most common reduced voltage starters. They are used in an attempt to reduce the start current applied to the motor during start as a means of reducing the disturbances and interference on the electrical supply.

Reliable Motor Protection and Control

Designed for three-phase motors, the FUJI SC-8 Star Delta Starter provides superior protection against short circuits and overheating. Its advanced control features, including auxiliary contacts and a recommended circuit breaker, ensure safe and reliable motor operation in diverse environments.

Versatile and Energy Efficient

With its ability to operate at multiple voltages and frequencies (50/60 Hz), the SC-8 suits a wide array of industrial settings. The low energy consumption and high efficiency support sustainable and cost-effective motor management.

Convenient Installation and Durable Build

Weighing just 1.85 kg and featuring a compact, panel-mount design, the starter is easy to install and maintain. Its construction with high-grade plastic and metal, along with IP20 protection, ensures longevity and resilience, even in demanding industrial conditions.

FAQ's of FUJI SC-8 STAR DELTA STARTER:

Q: How does the FUJI SC-8 Star Delta Starter protect motors during operation?

A: The FUJI SC-8 Star Delta Starter offers both short circuit and overheating protection, utilizing recommended breakers and built-in safety features to safeguard motors from electrical faults and excessive temperature, ensuring reliable and extended motor life.

Q: What is the process for wiring and installing the FUJI SC-8 Star Delta Starter?

A: Installation involves mounting the unit on a panel, connecting screw terminals for input and output power, and wiring the coil to the appropriate control voltage (220V-415V AC). Adhere to IEC 60947-4-1 standards and use the recommended breaker for optimal protection.

Q: When should I use a Star Delta Starter like the FUJI SC-8 for my motor?

A: Star Delta Starters are most effective for large three-phase induction motors that require reduced current during startup. Use the FUJI SC-8 when soft motor starting and protection against overloads and short circuits are needed.

Q: Where can the FUJI SC-8 Star Delta Starter be installed?

A: Thanks to its compact, panel-mount design and IP20 protection, the FUJI SC-8 is suitable for installation in industrial control panels and enclosures in factories, workshops, or any environment requiring motor control.

Q: What benefits does the high durability and energy efficiency of the SC-8 provide?

A: High durability ensures a long product lifespan, reducing maintenance costs, while its energy-efficient operation lowers power usage, contributing to overall operational savings and system reliability.

Q: How does the auxiliary contact configuration (1NO+1NC) enhance control capabilities?

A: The auxiliary contacts allow integration with additional control circuits, such as signal lamps or remote monitoring systems, expanding usage possibilities and improving operational flexibility.
