SIEMENS 3RT-2326 CONTACTOR

Name: SIEMENS 3RT-2326 CONTACTOR
Brand: RAJ ELECTRICALS

Get a Price/Quote

MOQ : 10 Pieces

SIEMENS 3RT-2326 CONTACTOR Specification

Humidity %
Up to 95% RH (Non-Condensing)

Efficiency
High Switching Efficiency

Mounting Type
DIN Rail / Panel Mount

Insulation Material
Thermoplastic

Overheating Protection
Thermal Overload Relay Compatible

Surface Finish
Matte

Shape
Rectangular

Feature
High Mechanical Durability, Reliable Switching

Operating Temperature
-25C to +60C

Power Factor
0.8

IP Rating
IP20

Connector Type
Screw Connector

Product Type
Contactor

Application
Motor Control, Power Switching

Protection Level
IP20

Frequency (MHz)
50/60 Hz

Rated Voltage
230 V AC

Energy Consumption
4.2 VA (Holding)

Output Type
NO + NC Contacts

Color
Grey/Black

Dimension (L*W*H)
80 x 45 x 74 mm

Weight
450 g

Size
Standard

Phase
Three Phase

Input Voltage
230 V AC

Connection Type
Screw Terminals

No Of Poles
3

Material
Thermoplastic/Metal

Coil Voltage
230 V AC 50/60 Hz

Rated Operational Current Ie (AC-3)
9A

Storage Temperature
-55C to +80C

Mechanical Life
Over 10 Million Operations

Vibration Resistance
5g (10-150 Hz)

Permissible Mounting Position
Any

Auxiliary Contacts
1 NO + 1 NC

Dielectric Strength
2500V AC

Electrical Life
Above 1 Million Operations

Short Circuit Protection
10 kA (with recommended fuse)

Standards
IEC 60947-4-1, VDE 0660

Control Voltage Range
184-253 V AC

SIEMENS 3RT-2326 CONTACTOR Trade Information

Minimum Order Quantity
10 Pieces

Payment Terms
Cash in Advance (CID), Cheque, Telegraphic Transfer (T/T)

Sample Available
Yes

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

About SIEMENS 3RT-2326 CONTACTOR

Raj Electricals Offering SIEMENS 3RT-2326 CONTACTOR At Bhavnagar, Gujarat, India.

We are engaged in the supply, dealing, distribution, export and import of the widest range of electrical and electronic items that would suit every type of project, economy and medium.

Product Specification :-

Type :- Electric Contactor

Make :- Siemens

Ith :- 40A

Auxiliary Contacts :- 1NO + 1NC

Model :- 3RT 2326

Condition :- Refurbished

Breaking Capacity :- 50 kA

Voltage :- 415V AC

Frequency :- 50-60 Hz

For More Details

WhatsApp or call on :- +919426838080, +919904838080.

YouTube : https://www.youtube.com/@rajelectricals5253

Google : https://g.co/kgs/WCmt5a

Instagram : https://www.instagram.com/rajelectric52/

Facebook : https://www.facebook.com/RajElectricals52/

Website : https://www.rajelectrics.com/

Engineered for Exceptional Durability

The SIEMENS 3RT-2326 Contactor combines high mechanical strength and long service life, with over 10 million mechanical and more than 1 million electrical operations. Constructed with thermoplastic and metal components, it meets international standards, ensuring reliable performance even in demanding industrial conditions. Its matte surface finish and robust insulation material further enhance durability.

Flexible Installation and Application Versatility

Suitable for both DIN rail and panel mounting, this contactor fits easily into various control panels and equipment. Designed to handle three-phase motor control and general power switching, it operates efficiently in environments with temperatures ranging from -25C to +60C and high humidity up to 95% non-condensing. It supports standard motor protection schemes via thermal overload relay compatibility.

Safe and Efficient Operation

With a rated voltage of 230 V AC, reliable screw terminals, and IP20 protection, the SIEMENS 3RT-2326 ensures user safety and operational efficiency. Its vibration resistance (up to 5g, 10-150 Hz) and dielectric strength of 2500 V AC deliver stable performance even in conditions prone to electrical or mechanical disturbances.

FAQ's of SIEMENS 3RT-2326 CONTACTOR:

Q: How can I install the SIEMENS 3RT-2326 Contactor in my control panel?

A: The SIEMENS 3RT-2326 can be installed using either DIN rail or panel mounting methods, providing flexibility for various panel configurations. Simply connect the wires using the screw terminals, and ensure proper alignment as per the wiring diagram for your application.

Q: What are the benefits of the auxiliary contacts (1 NO + 1 NC) included with this contactor?

A: The integrated auxiliary contacts enable you to expand control functionality, such as signaling or interlocking circuits, allowing for more versatile automation and operational safety within your motor control or power switching setup.

Q: When should I use short circuit protection with this contactor?

A: For safe operation, always use the recommended fuse to achieve a short circuit protection rating of 10 kA. This ensures your installation remains safeguarded against unexpected surges or faults, preserving the longevity of your equipment.

Q: Where is the SIEMENS 3RT-2326 commonly used?

A: This contactor is widely used in industrial motor control, power switching, and related applications where reliability and compliance with international safety standards are critical. It is suitable for installation in factories, plant control rooms, and commercial electrical panels.

Q: What is the process for ensuring thermal overload protection with this device?

A: To ensure overheating protection, pair the SIEMENS 3RT-2326 with a compatible thermal overload relay. This combination automatically interrupts the electrical circuit if excessive heat is detected, thus protecting your motor and system components.

Q: How does the high mechanical and electrical life benefit users?

A: With over 10 million mechanical operations and more than 1 million electrical operations, the contactor offers exceptional longevity. This translates to reduced maintenance costs, lower downtime, and higher reliability for critical installations.

Q: Can the contactor operate reliably in high humidity or varying temperatures?

A: Yes, the SIEMENS 3RT-2326 is designed for environments with up to 95% relative humidity (non-condensing) and an operating temperature range from -25C to +60C, making it suitable for diverse and challenging industrial locations.
