HYUNDAI (HBS-103C) 20A 3P MCCB

Name: HYUNDAI (HBS-103C) 20A 3P MCCB
Brand: RAJ ELECTRICALS

Get a Price/Quote

MOQ : 10 Pieces

HYUNDAI (HBS-103C) 20A 3P MCCB Specification

Phase
Three Phase

Breaking Capacity
25kA at 415V AC

Mechanical Life
Up to 10,000 operations

Rated Short Circuit Making Current
Adjustable

Rated Short Circuit Breaking Current
25kA

Product Type
Moulded Case Circuit Breaker (MCCB)

Installation Options
DIN Rail or Panel Mounting

Function
Automatic circuit protection against overload & short circuit

Poles Number
3P

Rated Voltage
415V AC

Rated Current
20A

Rated Frequency
50/60 Hz

Curves
Type C

Temperature Protection
Yes

Weight
Approx 800g

Color
Grey

Housing Material
High strength thermoset plastic

Ambient Temperature Withstand
Up to 50C without derating

Tripping Type
Thermal Magnetic

Operating Temperature Range
-5C to +40C

Rated Insulation Voltage
690V AC

Mounting Position
Any orientation

Terminal Type
Screw terminals

HYUNDAI (HBS-103C) 20A 3P MCCB Trade Information

Minimum Order Quantity
10 Pieces

Payment Terms
Cash in Advance (CID), Cheque, Letter of Credit (L/C)

Sample Available
Yes

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

About HYUNDAI (HBS-103C) 20A 3P MCCB

HYUNDAI (HBS-103C) 20A 3P MCCB Available In Stock At Raj Electricals, Bhavnagar, Gujarat, India.

We are engaged in the supply, dealing, distribution, export and import of the widest range of electrical and electronic items that would suit every type of project, economy and medium.

Product Specification :-

Type :- MCCB (Moulded Case Circuit Breaker)

Make :- HYUNDAI

Ampere :- 20A

Pole :- 3P

Model :- HBS-103C

Condition :- Refurbished

Breaking Capacity :- 7.5 kA

Voltage :- 415V AC

Frequency :- 50-60 Hz

For More Details

WhatsApp or call on :- +919426838080, +919904838080.

YouTube : https://www.youtube.com/@rajelectricals5253

Google : https://g.co/kgs/WCmt5a

Instagram : https://www.instagram.com/rajelectric52/

Facebook : https://www.facebook.com/RajElectricals52/

Website : https://www.rajelectrics.com/

Reliable Circuit Protection

With thermal-magnetic tripping and high breaking capacity, the HYUNDAI (HBS-103C) MCCB is built to prevent electrical overloads and short circuits efficiently. Its advanced technology and rugged design enable consistent performance in demanding industrial environments.

Versatile Installation Options

Supporting both DIN rail and panel mounting, this MCCB can be installed in any orientation, providing flexibility for a wide range of electrical cabinet designs. Its compact profile (approx. 800g) and screw terminals simplify integration.

Engineered for Harsh Conditions

Housed in high-strength thermoset plastic, this unit is capable of withstanding ambient temperatures up to 50C without derating. The wide operating temperature range (-5C to +40C) ensures reliable functionality in challenging settings.

FAQ's of HYUNDAI (HBS-103C) 20A 3P MCCB:

Q: How does the HYUNDAI (HBS-103C) 20A 3P MCCB protect electrical systems?

A: This MCCB provides automatic protection by interrupting the circuit in case of overload or short-circuit conditions, utilizing a thermal-magnetic trip mechanism for rapid and reliable response.

Q: What are the mounting options and orientations for this MCCB?

A: The MCCB can be installed either on a DIN rail or panel and is designed to operate reliably in any mounting orientation, offering installation flexibility.

Q: When should the HYUNDAI (HBS-103C) 20A 3P MCCB be used?

A: It is ideal for safeguarding three-phase circuits in industrial or commercial settings where reliable protection and a rated current of 20A are required at voltages up to 415V AC and 690V insulation.

Q: Where is this MCCB typically installed?

A: It is commonly used in electrical panels and distribution boards within manufacturing plants, commercial facilities, and infrastructure projects to protect critical equipment and wiring.

Q: What is the process for connecting cables to the MCCB terminals?

A: Cables should be securely fastened using the designated screw terminals, ensuring proper tightness and compatibility with the MCCB's rated specifications to maintain safety and performance.

Q: What are the benefits of choosing this particular MCCB model?

A: Benefits include high breaking capacity (25kA at 415V AC), robust construction, adjustable short circuit making current, long mechanical life (up to 10,000 operations), and resistance to elevated ambient temperatures up to 50C.
