HYUNDAI (HBS-103C) 100A 3P MCCB

Name: HYUNDAI (HBS-103C) 100A 3P MCCB
Brand: RAJ ELECTRICALS

Get a Price/Quote

MOQ : 3 Pieces

HYUNDAI (HBS-103C) 100A 3P MCCB Specification

Rated Short Circuit Breaking Current
25kA

Phase
Three Phase

Mechanical Life
10,000 Operations

Rated Short Circuit Making Current
50kA

Breaking Capacity
25kA @ 415V

Product Type
Moulded Case Circuit Breaker (MCCB)

Installation Options
Fixed, Surface Mounting

Function
Overload and Short Circuit Protection

Poles Number
3 Poles (3P)

Rated Voltage
415V AC

Rated Current
100A

Rated Frequency
50/60 Hz

Curves
Type C

Temperature Protection
Yes

Weight
Approx. 1.55 kg

Color
Grey & Black

Ambient Temperature Range
-5C to 40C

Utilization Category
AC-22A

Operating Position
Vertical & Horizontal

Degree of Protection
IP20

Trip Mechanism
Thermal Magnetic

Terminal Connection
Screw Type

Contact Position Indicator
Yes (ON/OFF)

Insulation Voltage (Ui)
690V

Model Number
HBS-103C

HYUNDAI (HBS-103C) 100A 3P MCCB Trade Information

Minimum Order Quantity
3 Pieces

Payment Terms
Cash in Advance (CID), Cheque, Letter of Credit (L/C)

Sample Available
Yes

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

About HYUNDAI (HBS-103C) 100A 3P MCCB

HYUNDAI (HBS-103) 100A 3P MCCB Available In Stock At Raj Electricals, Bhavnagar, Gujarat, India.

We are engaged in the supply, dealing, distribution, export and import of the widest range of electrical and electronic items that would suit every type of project, economy and medium.

Product Specification :-

Type :- MCCB (Moulded Case Circuit Breaker)

Make :- Hyundai

Ampere :- 100A

Pole :- 3P

Model :- HBS-103C

Condition :- Refurbished

Breaking Capacity :- 7.5 kA

Voltage :- 415V AC

Frequency :- 50-60 Hz

For More Details

Whats App or call on :- +919426838080, +919904838080.

YouTube : https://www.youtube.com/@rajelectricals5253

Google : https://g.co/kgs/WCmt5a

Instagram : https://www.instagram.com/rajelectric52/

Facebook : https://www.facebook.com/RajElectricals52/

Website : https://www.rajelectrics.com/

Comprehensive Circuit Protection

The HBS-103C MCCB provides dual-function safeguarding through thermal and magnetic trip mechanisms, defending electrical circuits from both overloads and short circuits. Designed for use in demanding environments, this breaker maintains reliable performance within ambient temperatures of -5C to 40C, ensuring the safety and longevity of your electrical installations.

Versatile and Easy Installation

This circuit breaker supports both vertical and horizontal mounting, and its screw-type terminals offer straightforward, secure connections. Suitable for fixed, surface-mounted installations, the HBS-103C simplifies integration within new or existing panel boards, making it a practical choice for engineers and technicians.

High Durability and Maximum Safety

Manufactured to withstand up to 10,000 mechanical operations, the MCCB boasts a sturdy build with a mechanical life designed for repeated use. Its IP20 degree of protection and clear ON/OFF contact position indicator further enhance safe operation, reducing maintenance efforts and ensuring dependable circuit isolation.

FAQ's of HYUNDAI (HBS-103C) 100A 3P MCCB:

Q: How do I install the HYUNDAI HBS-103C MCCB in my electrical panel?

A: The HBS-103C MCCB features screw-type terminals and supports fixed, surface mounting. Ensure the breaker is securely positioned either vertically or horizontally, connect the input and output wires to the terminal screws, and verify all connections are tightened for robust conductivity and safety.

Q: What type of protection does the HYUNDAI HBS-103C MCCB offer?

A: This MCCB provides comprehensive overload and short-circuit protection using a thermal-magnetic trip mechanism. It is designed to interrupt currents up to 25kA at 415V, safeguarding three-phase electrical systems from damage or fire risk.

Q: When should I use the HBS-103C in my installation?

A: Install the HBS-103C MCCB whenever you require protection for circuits with up to 100A current rating, particularly in commercial, industrial, or large residential three-phase supply systems where reliable fault interruption is critical.

Q: Where can the HYUNDAI HBS-103C MCCB be installed?

A: This MCCB is suitable for installation in electrical distribution panels and switchboards, supporting both surface mounting. Its IP20 protection makes it ideal for indoor environments where accidental contact with live parts must be prevented.

Q: What is the process for resetting the breaker after it trips?

A: After the breaker trips due to overload or short circuit, switch the handle to the OFF position to reset the mechanism. Then, return it to the ON position to restore normal operation, making sure to investigate and resolve the cause of the trip before resetting.

Q: How does the contact position indicator benefit users?

A: The MCCB has a built-in ON/OFF contact position indicator, enabling operators to easily see the breaker's status at a glance. This feature improves safety checks and simplifies troubleshooting in electrical panels.
