CROMPTON GREAVES 3 PHASE INDUCTION MOTOR

Send Inquiry

Request To Call Back

CROMPTON GREAVES 3 PHASE INDUCTION MOTOR

Get a Price/Quote

MOQ : 3 Pieces

CROMPTON GREAVES 3 PHASE INDUCTION MOTOR Specification

Efficiency
IE2

Surface Finish
Powder Coated

Feature
Robust Construction, High Efficiency, Low Vibration

Power Factor
0.8

Shape
Cylindrical

Overheating Protection
YES

Mounting Type
Foot Mounted

IP Rating
IP55

Operating Temperature
-20C to 50C

Humidity %
Up to 95%

Insulation Material
Class F

Connector Type
Terminal Box

Product Type
Induction Motor

Application
Industrial Machinery, Pumps, Fans, Compressors

Protection Level
High (Standard Industrial)

Frequency (MHz)
50 Hz

Rated Voltage
415 V

Energy Consumption
Efficient

Output Type
Rotational Mechanical Output

Color
Green

Dimension (L*W*H)
410 x 265 x 300 mm

Weight
45 kg

Input Voltage
415 V AC

Phase
3 Phase

Size
Standard

Connection Type
Star/Delta

No Of Poles
4

Material
Cast Iron

Cooling Type
Totally Enclosed Fan Cooled (TEFC)

Starting Method
DOL/Star-Delta

Altitude
Up to 1000 m above sea level

Ambient Temperature
Up to 50C

Frame Size
112M

Thermal Class
Class F

Bearings
Double Sealed Ball Bearings

Rotor Type
Squirrel Cage

Noise Level
Below 75 dB

Speed
1440 RPM

Duty Type
S1 Continuous

Rated Power
5 HP / 3.7 kW

CROMPTON GREAVES 3 PHASE INDUCTION MOTOR Trade Information

Minimum Order Quantity
3 Pieces

Payment Terms
Cash in Advance (CID), Cheque

Main Domestic Market
All India

About CROMPTON GREAVES 3 PHASE INDUCTION MOTOR

RAJ PANELS & MOTORS OFFERING YOU 3 PHASE INDUCTION MOTORS IN VARIOUS RANGE OR VARIOUS BRANDS BHVNAGR GUJARAT.

SPECIFICATION:

TYPE : INDUCTION MOTOR

MAKE : MADE IN CROMPTON GREAVES

MODEL : 7.5 HP / 1440 RPM

15 HP / 960 RPM

CONDITION : REFURBISHED

FREQUENCY : 50 HZ

FOR MORE DETAILS,

OR VISIT US AT : NEAR RAILWAY CROSSING,KUMBHARWADA,BHAVNAGAR,(GUJ.) 364001

Engineered for Efficiency and Durability

This 3 Phase Induction Motor from Crompton Greaves offers a blend of high energy efficiency (IE2), robust construction, and reliable performance under continuous duty (S1). The powder-coated cast iron frame, double sealed bearings, and TEFC cooling provide outstanding protection, ensuring longevity even in demanding conditions. With an IP55 rating, it effectively resists dust and moisture, making it ideal for harsh environments.

Versatile Industrial Applications

The Crompton Greaves motor is purpose-built for a variety of industrial settings, including driving pumps, fans, compressors, and other machinery. Its versatile connection options (star/delta), combined with a standard foot mounting, streamline installation and integration within existing setups. The motor's low vibration and noise level (below 75 dB) enhance workplace safety and comfort.

FAQ's of CROMPTON GREAVES 3 PHASE INDUCTION MOTOR:

Q: How is the Crompton Greaves 3 Phase Induction Motor typically started?

A: This motor supports both DOL (Direct-On-Line) and Star-Delta starting methods, offering flexibility for diverse operational requirements and ensuring efficient motor start-up while minimizing electrical and mechanical stress.

Q: What makes the motor suitable for continuous industrial use?

A: Engineered for S1 continuous duty, the motor is designed to operate without interruption under full load. Features like class F thermal insulation, robust cast iron construction, and TEFC cooling ensure long-term reliability in demanding industrial environments.

Q: Where can this 3 Phase Induction Motor be installed?

A: The motor is foot-mounted for secure installation and can be used in a wide range of industrial applications, including pumps, fans, compressors, and general machinery situated in environments with temperatures from -20C to 50C and altitudes up to 1000 meters.

Q: What are the key benefits of using this motor in industrial machinery?

A: Key benefits include high efficiency (IE2) for reduced energy costs, reliable performance under harsh conditions, low vibration for machinery longevity, and noise levels below 75 dB for a safer work environment. Its robust design and protection (IP55) further enhance operational safety and performance.

Q: How does the motor protect against overheating and environmental damage?

A: The motor features built-in overheating protection and is equipped with class F insulation. Its IP55 rating safeguards against dust and water ingress, while double sealed ball bearings prevent contaminants from reaching critical internal components.

Q: What process should be followed for motor connection and operation?

A: Ensure proper electrical connection via the terminal box, selecting star or delta configuration as required by your application. Verify supply voltage is 415 V AC at 50 Hz. Follow standard industrial safety and installation practices for optimal performance and longevity.
