ABB (SACE S4N) 100A 3P MCCB

Name: ABB (SACE S4N) 100A 3P MCCB
Brand: RAJ ELECTRICALS

Get a Price/Quote

MOQ : 5 Pieces

ABB (SACE S4N) 100A 3P MCCB Specification

Breaking Capacity
36 kA at 415V AC

Phase
Three Phase

Rated Short Circuit Making Current
72 kA (peak)

Rated Short Circuit Breaking Current
36 kA

Mechanical Life
20,000 operations

Product Type
Moulded Case Circuit Breaker (MCCB)

Installation Options
Panel Mounting

Function
Protection against overload and short circuit

Poles Number
3 Pole (3P)

Rated Voltage
690V AC

Rated Current
100A

Rated Frequency
50/60 Hz

Curves
Thermal Magnetic Release

Temperature Protection
Thermal-magnetic protection

Weight
1.4 kg (approx.)

Color
Grey

Degree of Protection
IP20

Insulation Voltage (Ui)
800V

Accessories
Auxiliary Contact, Shunt Trip (optional)

Terminal Type
Box Terminals

Trip Unit Type
Fixed Thermal/Fixed Magnetic

Rated Impulse Withstand Voltage (Uimp)
8 kV

Frame Size
S4

Utilization Category
A

Mounting Position
Any Position

Ambient Operating Temperature
-25C to +70C

ABB (SACE S4N) 100A 3P MCCB Trade Information

Minimum Order Quantity
5 Pieces

Payment Terms
Cash in Advance (CID), Cheque, Letter of Credit (L/C)

Sample Available
Yes

Main Export Market(s)
Middle East, Africa

Main Domestic Market
All India

About ABB (SACE S4N) 100A 3P MCCB

ABB (SACE S4N) 100A 3P MCCB Available In Stock At Raj Electricals, Bhavnagar, Gujarat, India.

We are engaged in the supply, dealing, distribution, export and import of the widest range of electrical and electronic items that would suit every type of project, economy and medium.

Product Specification :-

Type :- MCCB (Moulded Case Circuit Breaker)

Make :- ABB

Ampere :- 100A

Pole :- 3P

Model :- SACE S4N

Condition :- Refurbished

Breaking Capacity :- 35 kA

Voltage :- 415V AC

Frequency :- 50-60 Hz

For More Details

Whats App or call on :- +919426838080, +919904838080.

YouTube : https://www.youtube.com/@rajelectricals5253

Google : https://g.co/kgs/WCmt5a

Instagram : https://www.instagram.com/rajelectric52/

Facebook : https://www.facebook.com/RajElectricals52/

Website : https://www.rajelectrics.com/

Advanced Thermal-Magnetic Protection

The SACE S4N MCCB uses a fixed thermal and magnetic trip unit to provide comprehensive protection against both overload and short-circuit faults. Its rapid response and precise intervention help ensure your system remains secure and minimize downtime, making it ideal for safeguarding critical loads in any three-phase setup.

Rugged Design Suited for Varied Environments

Engineered to withstand harsh conditions, the SACE S4N operates efficiently between -25C and +70C. Its robust insulation (Ui 800V), high-rated impulse withstand voltage (8 kV), and IP20 protection build confidence in its performance, even in demanding industrial environments. The grey enclosure and 1.4 kg weight offer easy handling during installation.

Flexible Installation and Accessory Options

Installation is versatile, allowing placement in any mounting position within panel boards. The MCCB's box terminal design ensures secure connections, while auxiliary contacts and shunt trips can be added for enhanced monitoring and remote control functionality, adapting to tailor-made protection and management needs.
