GE 800A AIR CIRCUIT BREAKER

Get a Price/Quote

MOQ : 100 Pieces

GE 800A AIR CIRCUIT BREAKER Specification

Rated Short Circuit Making Current
110 kA

Rated Short Circuit Breaking Current
50 kA

Mechanical Life
10,000 Operations

Phase
Three Phase

Breaking Capacity
50 kA

Product Type
Air Circuit Breaker

Installation Options
Fixed or Drawout

Function
Overcurrent, Short Circuit, and Earth Fault Protection

Poles Number
3 Poles

Rated Voltage
690V AC

Rated Current
800A

Rated Frequency
50/60 Hz

Curves
Type C & D

Temperature Protection
Yes

Weight
Approx. 55 kg

Color
Black & Grey

Rated Insulation Voltage
1000V

Mounting
Panel Mounted

Service Condition
Indoor Use

Trip Unit Type
Microprocessor/ Electronic/ Thermal-Magnetic

Rated Impulse Withstand Voltage
8kV

IP Rating
IP30

Electrical Life
4,000 Operations

Busbar Connection
Horizontal / Vertical Possible

Standards
IEC 60947-2

Operating Temperature
-5°C to +40°C

Auxiliary Contacts
Available (Optional)

GE 800A AIR CIRCUIT BREAKER Trade Information

Minimum Order Quantity
100 Pieces

Supply Ability
100 Pieces Per Day

Delivery Time
2 Days

Sample Available
Yes

Main Domestic Market
All India

About GE 800A AIR CIRCUIT BREAKER

Air circuit breaker is a circuit breaker for the purpose of protecting low voltage circuit, mainly for energizing and cutting off high current. It is used as the master of a factory and building, and as a main circuit breaker of a ship, and it is possible to attach various accessories according to the purpose.

Precision Protection and Adaptability

The GE 800A Air Circuit Breaker is engineered for high breaking capacity and reliable operation. Its flexibility accommodates both fixed and drawout installations, making it well-suited for a variety of indoor panel configurations. With options for trip units and auxiliary contacts, this circuit breaker can be tailored to fit specific monitoring and control requirements, thereby enhancing safety in electrical networks.

Built to Endure Tough Environments

Operating efficiently within a broad temperature range of -5C to +40C, the GE 800A ACB delivers consistent performance in challenging service conditions. Its insulation and impulse withstand capacities meet strict IEC 60947-2 standards, providing robust protection against voltage surges. The product's quality design and durable construction minimize maintenance and optimize system uptime.

FAQ's of GE 800A AIR CIRCUIT BREAKER:

Q: How can the GE 800A Air Circuit Breaker be installed in an electrical system?

A: The GE 800A Air Circuit Breaker can be installed in either a fixed or drawout configuration within a panel. It supports both horizontal and vertical busbar connections, making it adaptable to different panel layouts and operational needs.

Q: What types of trip units are available with the GE 800A Air Circuit Breaker?

A: This circuit breaker offers three types of trip units: Microprocessor, Electronic, and Thermal-Magnetic. These options allow for versatile protection and monitoring capabilities according to your system's specific safety and automation requirements.

Q: Where is the GE 800A Air Circuit Breaker suitable for use?

A: This model is intended for indoor use only, as specified by its IP30 rating. It is designed for installation in electrical distribution panels where robust protection and reliability are essential.

Q: What benefits come from using the GE 800A Air Circuit Breaker in power distribution applications?

A: It delivers reliable overcurrent, short circuit, and earth fault protection, meeting IEC 60947-2 standards. Its high breaking capacity (50kA), long mechanical life (10,000 operations), and support for auxiliary contacts ensure safety, system flexibility, and easy integration into advanced control systems.

Q: When should auxiliary contacts be considered for this air circuit breaker?

A: Auxiliary contacts are available as an option and should be considered when remote signaling or advanced integration with control and monitoring systems is needed, such as in automation or critical power infrastructure.

Q: What process is involved in mounting the GE 800A Air Circuit Breaker?

A: Mounting is panel-based and requires securing the circuit breaker in place, connecting it to the busbar (either horizontally or vertically), and wiring according to the rated voltage and current. In drawout types, routine maintenance and replacements are simplified without the need for complete disconnection.

Q: How does the GE 800A Air Circuit Breaker enhance safety in power distribution?

A: By providing fast-acting protection against overcurrent, short circuit, and earth fault events, and with available temperature protection, the GE 800A minimizes the risk of electrical hazards and equipment damage, thus ensuring a secure and reliable power supply.
