L&t Mnx Series

Get a Price/Quote

L&t Mnx Series Specification

Insulation Material
Thermoset polymer, Self-extinguishing plastic

Shape
Rectangular modular

Power Factor
0.95

Surface Finish
Matt textured, Dust resistant

Overheating Protection
Yes (coil safe design)

IP Rating
IP20 (terminals), IP40 (housing)

Humidity %
95% RH (non-condensing)

Connector Type
Copper screw terminal

Operating Temperature
-5C to +50C

Feature
Silent operation, Compact design, Wide control voltage range

Efficiency
High efficiency, Low dropout

Mounting Type
35mm DIN Rail

Product Type
Modular Contactor

Application
HVAC, Lighting, Motor, Distribution Panel, Industrial Automation

Protection Level
IP20 (terminal) / IP40 (enclosure)

Frequency (MHz)
50/60 Hz

Rated Voltage
230V AC / 400V AC (variant specific)

Energy Consumption
Low coil consumption ~3.4VA (modular type)

Output Type
Normally Open (NO), Normally Closed (NC)

Color
Grey / White

Dimension (L*W*H)
59 x 80 x 82 mm (typical, varies per model)

Weight
~530g (frame size dependent)

Size
16A / 25A / 40A / 63A (current rating options)

Phase
Three Phase / Single Phase

Input Voltage
220V / 230V / 240V AC

Connection Type
Screw terminal

No Of Poles
3P/4P

Material
High-grade, Glass filled Nylon / Specially formulated engineering plastics

Ambient Storage Temperature
-25°C to +70°C

Electrical Life
100,000 operations at rated load

Vibration Resistance
No malfunction up to 5G

Shock Resistance
No malfunction up to 10G

Contact Material
Silver alloy

Standards Complied
IEC 60947-4-1, IS/IEC 60947-4-1

Mechanical Life
>1 Million operations

Control Circuit Voltage
12V, 24V, 48V, 110V, 230V AC/DC (model specific)

Auxiliary Contact
Optional 1NO+1NC snap-on module

L&t Mnx Series Trade Information

Payment Terms
Cash in Advance (CID)

Sample Available
Yes

Main Export Market(s)
Asia

Main Domestic Market
All India

About L&t Mnx Series

Discover the astonishing L&T MNX Series-a blue-ribbon, customizable contactor solution designed for unmatched reliability. Built to comply with IEC 60947-4-1 standards, these contactors boast uncommon mechanical life exceeding 1 million operations and exceptional electrical life at high loads. Benefit from fresh design features including optional auxiliary contact modules, silent operation, and a compact, modular build. Crafted from high-grade, glass-filled nylon and specialty engineering plastics, the MNX Series offers dust resistance, low energy consumption, and impressive protection levels, all at a delightful discount for bulk orders. Ideal for industrial automation and beyond.

L&T MNX Series: Adaptable Excellence for Diverse Applications

The MNX Series is engineered for specific and general use, seamlessly fitting applications such as HVAC, lighting, motors, distribution panels, and industrial automation. Notable special features include silent operation, compact modular design, and a wide control voltage range. Constructed from high-grade, glass-filled nylon and advanced polymers, these contactors offer uncommon durability and dust resistance, ensuring a long-lasting and efficient service life in demanding environments. Their versatility makes them a preferred choice across industries.

Effortless Transactions: Payment, Shipping, and Export Highlights

Valuation of the MNX Series is competitive, considering its blue-ribbon build and customizable options. Transactions are streamlined with flexible payment terms, while shipping is facilitated via major FOB ports in India. Our products are ready for global transportation, with primary export markets spanning Asia, the Middle East, and Africa. Inquiries on asking price, order volume, and logistics are promptly addressed by our support team to ensure a seamless acquisition and timely delivery.

FAQ's of L&t Mnx Series:

Q: How customizable is the L&T MNX Series for specific voltage or application needs?

A: The L&T MNX Series is exceptionally customizable, offering a diverse range of control circuit voltages, auxiliary contact options, and different current ratings to accommodate various applications such as HVAC, lighting, and industrial automation.

Q: What uncommon benefits does the L&T MNX Series offer compared to traditional contactors?

A: This series stands out with its astonishing mechanical life (over 1 million operations), silent function, superior dust resistance, and low energy consumption coils, making it a blue-ribbon choice for intensive and demanding setups.

Q: Where can the L&T MNX Series be used most effectively?

A: These contactors are ideal for use in distribution panels, HVAC systems, lighting setups, industrial automation, and motor control, ensuring high reliability and adaptability in both light and heavy-duty environments.

Q: What process should I follow to avail discount offers or bulk orders?

A: Please contact our distribution or sales team directly with your requirements. We offer attractive discounts for bulk orders and can guide you through the process from valuation to delivery and after-sales support.

Q: How does the L&T MNX Series ensure operational safety and long-term performance?

A: The series features coil safe designs for overheating protection, self-extinguishing insulation materials, robust shock and vibration resistance, and high-quality silver alloy contacts, delivering exceptional safety and durability.

Q: When is the right situation to choose a 3P variant over a 4P model in the MNX Series?

A: A 3P variant is typically preferred for three-phase loads like motors, while the 4P model suits power distribution systems needing a neutral line or additional protection for single-phase and certain automation panels.
